Architectural / Products / LED Puck / LED Puck Air
LED Puck Air Surface
Overview
The LED Puck Air surface mount is the smallest and most discreet option for installing a light with this level of output. It can be mounted both vertically and horizontally on various surfaces, including masonry, steel, timber, gypsum board (gyprock), and ceiling tiles. Its unique design also minimizes the impact on the mounting surface.
Specifications
TECHNICAL
8W
3 Step MacAdam Ellipse
L90 B10 >100,000h
CRI 80+ (CRI 90+ option)
PERFORMANCE
Up to 850lm (8W @ 4000k over 100lm/w)
OPTICS
Polycarbonate / PMMA
DISTRIBUTION
Available in a range of distributions:
Circular, Oval, Decorative, etc.
EMITTER OPTIONS
BINNING: 3-step bins, 2200K-5700K CCT Tunable White, RGBW and 17 colour options
MATERIAL
Marine Grade Aluminium
FINISHES
Anodised Black Matte (Standard)
Lens Ring Colour Options Available
AMBIENT OPERATING CONDITIONS
min. -40° / max. +55°
PROTECTION CLASS
IP67 / IK10
ELECTRICAL
24VDC
INSTALLATION
Ø55mm cut out
CONTROL
0-10 v | DALI | Phase | Casambi
DIMENSIONS & WEIGHT
Ø25mm x Ø150mm (standard body) 100g per luminaire (standard body).
See options and mounts for details
Lighting Options
Available in a range of white options (2200K-5700K CCT), Tunable White, or RGBW. Also available in 17 colours.
2200K / 2700K / 3000K / 3500K / 4000K / 5000 / 5700K /colour temperature
Photo Red / Violet / Royal Blue / Blue / Cyan / Green / Amber / Red-Orange / Red / Phosphor Blue / Phosphor Cyan / Phosphor Lime / Phosphor Amber / Phosphor Red-Orange / Phosphor Red / Phosphor Mint / Phosphor Yellow saturated colours
*For more detailed information, download the product Datasheet
Ideal For
- Outdoor Lighting
- Interior Lighting
- Retail
- Display Cases
- Galleries & Museums
